1/4" Foot With Guide

Details

Easily achieve a 1/4" (6mm) or scant 1/4" seams. Simply align the foot's guide with the edge of your fabric while sewing.

Compatible with the following HUSQVARNA® VIKING® machine groups: 1-9.

Additional Features

• Needle hole in the foot allows for needle position to be adjusted
• Place guide against the edge of your fabric for either 1/4" or scant 1/4" seams
• Red marking on the foot provides extra help navigating corners and fabric edges

Piecing:

The Adjustable 1⁄4” Foot with Guide is designed to help you achieve a 1⁄4 “(6mm) or scant 1⁄4” (less than 6mm) seam when piecing. The needle hole in the foot is oval shaped allowing you to adjust the needle position. The distance between the center needle position and the guide is 1⁄4” (6mm).

1. Snap-on the Adjustable 1⁄4” Foot with Guide. *
2. Select a straight stitch.
   a. For a 1/4” (6mm) seam; select a centered the needle position.
   b. For a scant 1/4” seam; adjust the needle position one or two steps to the right.
3. lace the fabric pieces right sides together under the presser foot, aligning the edges of the fabric with the guide on the foot.
4. Sew the fabric pieces together guiding the fabric so that the edges touch the guide.

5. Press the seam allowance.

Note: Depending on the weight of your fabric and thread it may be necessary to adjust the needle position to achieve your desired seam allowance. Move the needle to the right to decrease the seam allowance and to the left to increase it. You can safely move the needle three steps in either direction, but not more.

* Do not use the Straight stitch plate when using the Adjustable 1⁄4” Foot with Guide.

Topstitching:

The Adjustable 1⁄4” Foot with Guide is also wonderful for topstitching. Adjust the needle position and use the guide to place your stitching exactly where you want it on your blocks, garments or home decor projects.

1. Snap-on the Adjustable 1⁄4” Foot with Guide.
2. Select a straight stitch, triple straight stitch or the mock hand quilting stitch.
Adjust the needle position as desired if needed.
3. Place the project under the presser foot so that the guide on the foot runs in the ditch of the seam or along the edge of the fabric. Sew.

Note: Red markings on the Adjustable 1⁄4” Foot with Guide help you align the fabric when you start sewing, at corners and at the end of your fabric.
